Mystic Cartridge
features
The body is machined from solid Aluminium alloy and mass tuned to the generator for optimum support and control of unwanted mechanical vibrations. The body is threaded to accept the two supplied stainless steel thumb screws that are also designed for correct coupling of the cartridge body to the tonearm head-shell. Machined on top of the Mystic cartridge are three specifically designed contact points that provide the exact mechanical coupling required by the Mystic cartridge.
In addition there is also an alignment ridge on the front top that assists with the mounting of the Mystic to any complementing Vertere tonearm.
The generator utilizes a Samarium-Cobalt magnet with a Cross coil made of pure copper wires. The aluminium tube cantilever supports a Micro Elliptical bonded diamond stylus tip that is designed for maximum tractability without compromising on high frequency response or increased surface noise. This provides a wide band frequency response of below 10Hz to 40kHz that coupled with an output of 0.5mV will provide a lifelike dynamic range with depth and precision.
Manuals & Support
technical specifications
Type
Moving Coil Phono Cartridge
Mounting
M2.5 Threaded Holes
Special Tri-Point Contact
Output Level
0.5mV
Frequency Response
10 Hz -40 kHz
Coil Impedance (per Channel)
40Ω
680 Ω – 1k5 Ω
Recommended Load
220pF – 470 pF
Channel Balance
Better than 1.0 dB
Recommended Tracking Weight
2.0g
Cantilever
Aluminum Tube
Stylus
Micro Elliptical Diamond
Weight
9.1g
